What Are the Processing Methods of Graphite Electrodes?

There are three main types of graphite electrode processing: pressurized vibration method, numerical control automatic forming method and mechanical processing method.

1. The pressurized vibration method of graphite electrode

The pressurized vibration method requires a special machine tool, and the electrode master pattern has the opposite shape to the electrode. The graphite material and the forming tool are placed relative to each other during processing, leaving a certain gap. The machining fluid, which is mixed with water and abrasives, is injected into it. While passing the machining fluid, the graphite and the forming tool are ultrasonically vibrated. Under the action of the abrasive impact force, the graphite is slightly exfoliated into the required shape. The abrasive is SiC, B4C or diamond. The coarser the abrasive, the faster the processing speed. When the machine is working, it adopts the sealed type and water curtain type for processing. It is suitable for mass production of types of graphite electrodes for electric spark forming.

2. The numerical control automatic forming method of graphite electrode

The numerical control automatic forming method requires a dedicated graphite electrode forming machine, which adopts the numerical control method, has an automatic tool exchange device, and can accommodate multiple tools. In order to improve the processing environment, the graphite electrode is surrounded by a water curtain to prevent the graphite dust from dispersing. In addition, the wet machining method can also be used to prevent tool wear and graphite dust from scattering by water-soluble cutting fluid. The machine tool has a high-performance filter device, which can separate the cutting fluid and graphite chips, and can ensure continuous processing for a long time. It is an ideal special equipment for graphite electrode processing and is suitable for electrode processing for molds.

3. The machining method of graphite electrode

The machining method is the main method adopted by the general mold production units in China.

Graphite materials can be processed by turning, milling, drilling and grinding methods. In addition, graphite materials are prone to fly ash during mechanical processing, which will adversely affect processing equipment and operators.
